[Inspection principle] Using machine vision technology: automatic identify, classify and count the formed elements in urine with microscope automatic morphological methods.
[Test items] Red blood cells, white blood cells, pus cells, squamous epithelial cells, non-squamous epithelial cells, transparent casts, unclassified casts, crystals, bacteria, blood bacteria, sperm, mucus, etc.
[Test speed] 60 samples/hour.
[Detection mode] The microscope counts and classifies target identifications such as red blood cells, white blood cells, and crystals.
[Sample quantity] Minimum urine volume 2ml, minimum injection volume 0.5ml
[Sample processing] The sample can be directly tested without centrifugation.
[Injection method] Automatic trail injection, 10 samples on the machine at the same time.
[Accuracy] more than 90% (Artificail auxiliary judgments).
[Repeatability test] CV < 10%
[carrying pollution rate]< 0.05%
[False negative rate] < 3%
[Report form] xx/u l international universal quantitative unit, comprehensive graphic report of dry chemical analysis and urine formed elements quantitative analysis
[Dimensions] 420mm x 340mm x 395mm (length x width x height).
[Weight] 15kg
[Display] 5-inch LCD screen.
[Data Interface] A full set of computer data interfaces, can connect to dry chemical urine analyzer, printers and networks.
[Power Requirements] AC 220V+-10%, 50Hz
[Standard configuration] Built-in computer, standard display, mouse, keyboard, printer.
[Product characteristics]
Automatic trail injection, walk away, 10 samples on the machine at the same time, simple operation. Dedicated focusing fluid can be used to automatically calibrate the focal length of the microscope to ensure clear and complete sample capture. Samples do not need to be centrifuged and pretreatment, and sample injection, mixing, sampling, and precipitation are performed automatically. Automated target recognition and classification counting of acquired images; high-precision charge counting cell ensures accurate and stable detection of specimens, consistent conditions, standardized test results, high-precision sample sucking needles, tubes, and valves to ensure highly stable piping systems; The efficient automatic cleaning function effectively cleans the inner and outer walls of the sampling needle and the pipeline to avoid cross-contamination; Have self-learning function, the longer the usage time is, the higher the recognition rate is. It can be connected with urine analyzer and provide comprehensive reports on dry chemistry and sediment.
